Seamless Support from Design to Final Assembly

At karvi Interconnects, we go beyond PCB design — we actively support our customers through the entire PCB Assembly (PCBA) process, working directly with your chosen assembly vendors to ensure smooth production, functional quality, and timely delivery. Whether you're assembling a prototype or full-scale production batch, we help bridge the gap between design and manufacturing.

Our PCB Assembly Support Services Include

• BoM generation with vendor-specific part numbers
• Pick & Place (XY) files, centroid data, and polarity markings
• Assembly drawings with orientation, notes, and instructions

Design for Assembly (DFA) Review

• Component spacing and orientation checks
• Pad size, thermal relief, and footprint optimization
• Fiducial, tooling hole, and panelization guidance
• Single-side vs. double-side assembly constraints

Vendor Coordination & Support

• Collaborate with EMS partners or customer-chosen vendors
• Provide technical support during production
• Offer BOM alternates and sourcing support
• Support for RoHS, lead-free, IPC-Class II/III builds

Pre-Assembly Validation

• Validate assembly files (Gerber, BoM, CPL/XY)
• Panel design for automated pick & place
• Test point layout & Design for Testability (DFT)

We Support

• Prototype, low-volume, and high-volume assemblies
• SMT, Through-Hole, Mixed Technology builds
• Panelized assemblies and multi-board setups
• Complex packages like BGA, QFN, LGA, etc.

Why Our PCBA Vendor Support Makes a Difference

• Faster, reliable hand-off to your assembly partner
• Reduced pick-and-place and soldering errors
• Fewer redesigns caused by assembly constraints
• Trusted collaboration with local and global EMS vendors
• Support for NPI, pilot runs, and production scaling
